High-strength Chemcial Anchor Set
OEM Factory, Customization based on your designs.
Materials include carbon steel and stainless steel for your choice.
Surface treatments (except for stainless steel) include:
Cold galvanizing (average zinc layer thickness >5μm), suitable for ordinary environments.
Hot-dip galvanizing (average zinc layer thickness >45μm), suitable for corrosive environments.
Materials include carbon steel and stainless steel for your choice.
Surface treatments (except for stainless steel) include:
Cold galvanizing (average zinc layer thickness >5μm), suitable for ordinary environments.
Hot-dip galvanizing (average zinc layer thickness >45μm), suitable for corrosive environments.
-
Product Description
High-strength chemical anchor bolts can be used to anchor concrete to exterior structural members, using adhesive anchoring method. The materials used for the Daring high-strength chemical anchor bolts are carbon steel with a grade of 5.8 or higher, or 304/316 stainless steel, and are matched with corresponding types of glue tubes or adhesive.
-
Specifications
Type Drilling diameter(mm) Anchoring depth(mm) Maximum Anchorage Thickness(mm) Minimum substrate thickness(mm) M8*110 10 80 15 140 M10*130 12 90 20 160 M12*160 14 110 25 210 M16*190 18 125 35 210 M20*260 25 170 65 340 M24*300 28 210 65 370 M30*380 35 270 70 540
